S/N 序号 | Function Items 功能性项目 | Parameter 参数 | |||
1 | Model 型号 | FPAD360K-6 | FPAD480K-8 | FPAD600K-10 | FPAD720K-12 |
2 | Rated Power 额定功率 | 360KW | 480KW | 600KW | 720KW |
3 | Output Loop 输出回路 | 6 | 8 | 10 | 12 |
4 | Input Loop 输入回路 | Double Channel | |||
5 | Overall Size（mm） 外形尺寸（mm） | 900X800X2100 | 1700X800X2100 | 1700X800X2100 | 1700X800X2200 |
6 | Input Voltage 输入电压 | AC 380V±20% | |||
7 | Input Frequency 输入频率 | 50Hz±10% | |||
8 | Output Voltage Range 输出电压范围 | DC 200~1000V | |||
9 | Max. Output Current Of Each Channel 每路最大输出电流 | 250A | |||
10 | Constant Power Output Voltage Range 恒定功率输出电压范围 | DC 300~1000V | |||
11 | Max, Efficiency 最高效率 | ≥95%（50%~100% Rated Output Power） | |||
12 | Power Factor 功率因数 | ≥0.99（50%~100% Rated Output Power） | |||
13 | Voltage Regulation Accuracy 稳压精度 | ≤±0.5% | |||
14 | Current Regulation Accuracy 稳流精度 | ≤±1.0%（20%~100% Rated Output Power） | |||
15 | Degree of unbalance in the current equalization 均流不平衡度 | ≤±5% | |||
16 | Ripple Crest Peak 纹波峰峰值 | ≤1% | |||
17 | Class Of Protection 防护等级 | IP54 | |||
18 | Use Environment 使用环境 | Indoor or Outdoor | |||
19 | Noise 噪音 | ≤65dB | |||
20 | Heat Dissipation Mode 散热方式 | Forced Air Cooling | |||
21 | THD 总谐波失真 | ≤5%（50%~100% Rated Output Power） | |||
22 | Communication With The Terminal Cabinet 与终端柜通信方式 | CAN Communication | |||
23 | Operation Temperature 运行温度 | -20℃~+50℃ | |||
24 | Relative Humidity 相对湿度 | 5%~95% | |||
25 | Altitude 海拔高度 | ≤2000m | |||
26 | Installation Mode 安装方式 | Floor Mount | |||
S/N 序号 | Function Items 功能性项目 | Parameter 参数 |
1 | Model 型号 | FPDC60/120K |
2 | Output Voltage Range 输出电压范围 | DC 200~1000V |
3 | Number Of Guns 枪数 | Single/Double Gun |
4 | Max. Output Current Of Each Channel 每路最大输出电流 | 250A |
5 | Constant Power Output Voltage Range 恒定功率输出电压范围 | DC 300~1000V |
6 | Rated Power 额定功率 | 60KW |
7 | Max. Output Power 最大输出功率 | 250KW |
8 | Auxiliary Power Supply 辅助电源 | DC 12V |
9 | Electric Energy Measurement 电能计量 | Level 1.0 |
10 | Man-Machine Interface 人机界面 | 7“ Touch Screen LCD+LED Indicator Light |
11 | Charging Mode 充电模式 | Automatic Charging、By Time、By Power、By Amount |
12 | Starting Mode 启动方式 | Swipe Card、Scan Code、Password、VIN |
13 | Protection Function 保护功能 | Short Circuit、Over Temperature、Over Current、Leakage、Under Voltage、Over Voltage |
14 | Cloud Platform 云平台 | Cloud Fast Charging、Weijing Cloud、DAK Cloud、E-Charging |
15 | Charging Mode 充电模式 | Full Power Charge、AB Charge |
16 | Insulation Resistance 绝缘电阻 | ≥20MΩ |
22 | Communication With The Rectifier Cabinet 与整流柜通信方式 | CAN Communication |
18 | Networking Mode 联网方式 | Ethernet、4G |
19 | Class Of Protection 防护等级 | IP54 |
20 | Operation Temperature 运行温度 | -20℃~+50℃ |
21 | Storage Temperature 储存温度 | -40℃~+70℃ |
22 | Relative Humidity 相对湿度 | 5%~95% |
23 | Altitude 海拔高度 | ≤2000m |
24 | Installation Mode 安装方式 | Floor Mount |
25 | Size（mm） 尺寸（mm） | Single Gun Terminal：400X200X1610（WXDXH） Double Gun Terminal：550X230X1610（WXDXH） |
